| No-load speed |
2.500 – 8.000 rpm |
| Bit holder |
Collets up to 8 mm diameter |
| Rated power input |
750 W |
| Power output |
420 W |
| Spindle collar diameter |
43 mm |
| Weight |
1,7 kg |
| Length |
387 mm |
| Height |
77 mm |
| Max. collet diameter |
8 mm mm |
| Max. grinding tool diameter |
50 mm |
| Spanner size of locking nut |
19 mm² |
| Spanner size of grinding spindle |
13 mm² |
| Max. polishing tool diameter |
80 mm |
| Switch |
2-way |
Functions
- Constant Electronic
- Electronic
- Champion motor
- Direct cooling
- KickBack Stop
- Soft start
- Overload protection
Noise/vibration information
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
| Surface grinding up to diameter of 50 |
|
| Vibration emission value ah |
2.5 m/s² |
| Surface grinding up to diameter of 25 |
|
| Vibration emission value ah |
2.5 m/s² |
| Uncertainty K |
1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 82 dB(A); Sound power level 93 dB(A). Uncertainty K= 3 dB.
Available in 230v and 110v versions, please select the version from the drop down on the left.
